proxyabl

in-path routing, enforcement, and provider selection for llm and agentic apps

once a request is identified (identifiabl), transformed (transformabl), and authorized (validatabl), it needs to be sent to the right place.

which provider should handle this request? which model? under what context?

proxyabl answers that question.

it is the in-path gateway that sits between your apps and llm providers, enforcing routing rules and injecting identity and governance context into every call.

at a glance

proxyabl is the request routing and execution gateway for llm apps.

it lets you:

• forward requests to external or internal llm providers
• choose models based on cost, latency, risk, or tenant rules
• inject identity, governance, and routing metadata
• apply in-path enforcement before and after model calls
• implement fallbacks and multi-provider strategies

📦 implementation: ai-routing-gateway (roadmap)

why now?

as organizations adopt multiple llm providers and internal models, they need:

• a single entry point for all llm requests
• consistent routing behavior across teams and apps
• the ability to swap providers without changing app code
• tenant-aware and content-aware routing decisions
• a place to enforce in-path policy decisions

proxyabl turns your llm access into a governed endpoint rather than a set of scattered direct api calls.

designing the routing gateway for ai

within the shared requestcontext

all gatewaystack modules operate on a shared RequestContext object.

proxyabl is responsible for:

• reading: identity, metadata, modelRequest, policyDecision, limitsDecision
• writing: routingDecision (provider, model, region, alias) and normalized provider response

proxyabl receives policy-approved requests from validatabl and pre-flight constraints from limitabl, then:

• selects a provider and model
• injects identity and trace metadata
• applies routing rules (by tenant, risk, geography, or content type)
• forwards the request to the chosen provider
• normalizes the provider response shape

it becomes the central network and execution layer of gatewaystack.

the core functions

1. selectProvider — choose which provider should receive the request
selection can be based on tenant, content classification, region, cost, latency, or internal policy.

2. selectModel — choose the appropriate model for the request
for example, different models for summarization vs retrieval vs reasoning, or for different sensitivity levels.

3. injectContext — attach identity and governance metadata
ensures downstream systems receive user_id, org_id, roles, scopes, and policy decisions as headers or metadata.

4. forward — execute the call against the selected provider/model
wraps the provider api, normalizes request and response shapes as needed.

5. fallback — handle provider or model failures
retry, fallback to secondary providers, or gracefully degrade behavior based on configuration.

6. preflightChecks — final checks before execution
ensures the request still satisfies any pre-execution requirements (for example, global flags, maintenance modes, additional filters).

7. loadBalance — distribute traffic across provider backends
supports weighted round-robin, least-latency, or fail-over strategies across multiple endpoints for a given provider.

what proxyabl does

• centralizes llm provider access behind a single gateway
• enforces tenant-aware and content-aware routing
• injects identity and governance metadata into every call
• applies fallback and redundancy strategies
• isolates app code from provider-specific details
• populates the routingDecision field in RequestContext

proxyabl works with

• identifiabl to authenticate users (see )
• transformabl transform content (see )
• validatabl to make policy decisions (see )
• limitabl to enforce quotas or budgets (see )
• explicabl as the primary audit log (though proxyabl contributes metadata)

routing rules

proxyabl evaluates routing rules to select provider and model:

routing:
  - name: "sensitive-data-to-azure"
    priority: 1
    condition: content.metadata.classification == "sensitive"
    provider: "azure-openai"
    model: "gpt-4"

  - name: "eu-users-to-eu-region"
    priority: 2
    condition: identity.user.region == "eu"
    provider: "azure-openai-eu"
    model: "gpt-4"

  - name: "free-tier-to-cheap-model"
    priority: 3
    condition: identity.user.tier == "free"
    provider: "openai"
    model: "gpt-3.5-turbo"

  - name: "default"
    priority: 999
    provider: "openai"
    model: "gpt-4-turbo"

rules are evaluated in priority order, first match wins.

response normalization

proxyabl normalizes provider-specific responses to a unified format:

// unified response format (regardless of provider)
{
  content: "Response text",
  metadata: {
    provider: "openai",
    model: "gpt-4",
    tokens: { input: 100, output: 50 },
    latency_ms: 234,
    request_id: "req_abc123"
  }
}

this decouples app code from provider apis, enabling seamless provider switching.

fallback and redundancy

proxyabl implements multi-layered failover:

retry strategy:

• transient errors (429, 500, timeout): retry with exponential backoff
• max 3 attempts per provider

provider fallback:

• primary fails → secondary provider
• all providers fail → return graceful error

health checks:

• continuous monitoring of provider endpoints
• circuit breaker: disable failing providers temporarily
• auto-recovery when health restored

fallback_chain:
  - provider: "openai-primary"
    timeout: 10s
  - provider: "openai-secondary"
    timeout: 10s
  - provider: "anthropic"
    timeout: 15s

model aliasing & multi-provider workflows

apps reference logical model names, not provider-specific models:

aliases:
  smart-model:
    default: "gpt-4"
    overrides:
      - condition: identity.org_id == "healthcare_org"
        model: "azure-openai:gpt-4"  # HIPAA compliant
      - condition: identity.user.tier == "free"
        model: "gpt-3.5-turbo"

  fast-model:
    default: "gpt-3.5-turbo"

  code-model:
    default: "gpt-4-code-interpreter"

app code remains unchanged when swapping models:

// app requests "smart-model", proxyabl resolves to actual model
await gatewaystack.chat({ model: "smart-model", ... })

provider authentication

proxyabl manages provider-side authentication and secrets:

• secrets storage: provider api keys and credentials stored in secure secrets backend (vault, aws secrets manager, etc.)
• just-in-time injection: credentials injected only at execution time, never exposed to application code
• key rotation: supports credential rotation without redeploying or changing app code
• multi-tenancy: can use separate credentials per tenant, environment, or region
• audit trail: all credential access logged for security and compliance

example secrets configuration:

secrets:
  backend: "vault"
  vault_addr: "https://vault.company.com"
  providers:
    openai:
      path: "secret/gatewaystack/openai"
      key_field: "api_key"
    azure-openai:
      path: "secret/gatewaystack/azure"
      key_field: "api_key"
      tenant_specific: true  # separate keys per tenant

this keeps sensitive provider secrets out of application code and centralized in the gateway.

end to end flow

user
   → identifiabl       (who is calling?)
   → transformabl      (prepare, clean, classify, anonymize)
   → validatabl        (is this allowed?)
   → limitabl          (can they afford it? pre-flight constraints)
   → proxyabl          (where does it go? execute)
   → llm provider      (model call)
   → [limitabl]        (deduct actual usage, update quotas/budgets)
   → explicabl         (what happened?)
   → response

proxyabl is where approved requests actually become executed calls to llm providers — with routing decisions driven by identity, content, policy, and spend constraints.

integrates with your existing stack

proxyabl plugs into gatewaystack and your existing llm stack without requiring application-level changes. it exposes http middleware and sdk hooks for:

• chatgpt apps sdk
• model context protocol (mcp)
• oauth2 / oidc identity providers
• any llm provider (openai, anthropic, google, internal models)

getting started

for routing configuration examples:
→ routing patterns library
→ model aliasing guide
→ provider fallback strategies

for secrets and authentication:
→ secrets management guide

for implementation:
→ integration guide
